Blink Marine CAN Bus Keypads
Blink Marine are experts in CAN bus enabled keypads. With a wide option of keypads available from 4-15 Button, they are a perfect accompaniment to the Hardwire Electronics PDMs. Instead of needing to wire each individual switch to an input of the PDM, CAN bus keypads allow for a simple and robust system using just two CAN bus wire, power and ground.
Added benefits over a traditional switch panel include -
-
A huge range of over 1000 individual button inserts to choose from
-
RGB LED back lit buttons.
-
Multiple states per button, allowing for advanced functionality beyond a normal switch
-
IP67 water and dust ingress protection
-
Rotary dials with up-to 16 indentations and indication LEDs
-
Increased reliability
-
Output Fault status indication using the button LEDs
Blink Marine Keypad Range
6 Button CAN Bus Keypad
Racepad
15 Button CAN Bus Keypad with Dials
6 Button CAN Bus Keypad
15 Button CAN Bus Keypad
4 Button CAN Bus keypad
6 Button CAN Bus Keypad
15 Button CAN Bus Keypad
10 Button CAN Bus keypad
8 Button CAN Bus keypad
12 Button CAN Bus Keypad
10 Button CAN Bus keypad
Technical Statistics​
-
Operating Voltage: 12/24V.
-
Standby Current: <50mA.
-
Operating Temperature: -40°C to 70°C.
-
Construction: Silicone Rubber with polyurethane hardcoat.
-
IP Rating: IP67/IP69K water and dust resistant.
-
UV Protection: UVB 400 Hours.
-
Checmical Resistance: Deet, Engine Cleaner, Isopropyl Alcohol, Suntan Lotion, Multi-Purpose Cleaner, Orange Citrus Cleaner, Muriatic Acid.
-
Connectors: Deutsch DT 4-Pin
-
Switch Life: 3 million operations.
